GPRS / GSM modem Billionton (PCMCIA)


افرادی که بخواهند از طریق لب تاپ خود و سیم کارت به اینترنت وصل بشوند و فاکس و تلفن هم داشته باشند این مودم بهترین می باشد که به پورت PCMCIA وصل می شود.افرادی که بخواهند از طریق پورت USB  به کامپیوتر وصل شوند از مدل پائین می توانند استفاده کنند




This product is a PCMCIA to GSM/GPRS Card. It provides tri-band EGSM900, GSM1800 and GSM1900 capability to notebook PCs. This product uses GPRS module and Oxford PCMCIA to UART bridge controller.




Features:

■ Tri-band EGSM900, GSM1800 and GSM 1900.
■ GPRS multi-slot class 10- GPRS mobile station class B
■ Compliant to GSM phase 2/2+- Control via AT commands
■ Supports Windows 98se, Windows 2000, Windows ME, Windows XP



Specifications:

Interface :
■  PCMCIA Interface
    Provide PCMCIA 68pin connector for attachment to PC's.
■  GPRS Module
    SIM application tool kit
    Tri-band Antenna.
■  SIM Interface
    Supported SIM card: 3V.
    External SIM card reader.
■ Audio Interface
   4 point ear phone jack
Support Data, Voice, SMS and Fax function :
■  Data
    CSD transmission rates: 9.05 , 13.4 , 15.6 , 21.4 kbps.
    GPRS data downlink transfer: max. 85.6 kbps
    GPRS data uplink transfer: max. 42.8 kbps
    Coding scheme: CS-1, CS-2, CS-3 and CS-4
    Supports 2 protocols PAP (Password Authentication Protocol) and CHAP (Challenge Handshake Authentication Protocol)  commonly used for PPP connections.
    Support of Packet Switched Broadcast Control Channel (PBCCH) allows you to benefit from enhanced GPRS performance when offered by the network operators.
   Unstructured Supplementary Services Data (USSD) support
■  Fax
Group 3,Class 2
■  SMS
MT, MO, CB, Text and PDU mode
SMS storage: SIM card plus 25 SMS locations in the mobile equipment
Transmission of SMS alternatively over CSD or GPRS. Preferred mode can be user-defined.
Environmental
Operating Ranges Operating : Temperature 0 ~ 55℃
                                                       Humidity 10%-95%
Storage : Temperature -20 ~ 65℃
                 Humidity 10%-95%5.
Power Consumption : Operation max Operation Current : 840 mA/5V
                                        Class 4 (2W) at EGSM900.
                                        Class 1 (1W) at GSM1800 and GSM 1900.6.
LED Indication : Power LED- Active LED
Drivers support : Windows 98se/ME/2000/XP SP



GPRS / GSM modem Billionton (USB)


This product provides data and voice in a USB adapter. It lets you use e-mail, access internet and make phone call direct form your PC without any telephone line.




Features:

■ Dual-band EGSM900 and GSM1800
■ GPRS multi-slot class 8
■ GPRS mobile station class B
■ Compliant to GSMphase 2/2+
■ Control via AT commands



Specifications:

GPRS Module :
SIM application tool kit
Dual-band Antenna
Support Functions :
■ Data :
CSD up to 14.4 kbps
USSD
Non transparent mode
V.110
GPRS:max.85.6 kbps (downlink)
Coding scheme CS 1,,2,3,4
PPP—stack
■ Voice :
Half rate (HR), Full rate (FR), Enhanced full rate (EFR)
Basic handsfree operation
Echo cancellation
Noise reduction
■ Fax :
Group 3,Class 2
■ SMS :
Point-to-point MO and MT
SMS cell broadcast
Text and PDU mode
Mechanical : 105 x 45 x 25 mm (L x W x H)
Certification :
EMC/EMI: CE(CISPR22 class B)
Environment Operating Ranges : Operating Temperature : 0 ~ 55℃ / Humidity 10%-95%
                                                             Storage Temperature : -20 ~ 65℃ / Humidity 10%-95%
Power Consumption :
Sleep mode : 24.5 mA
Idle mode (registered) : 24.5 mA
Speech mode 450mA/ 5V (max) 2.0 A(peak)
Power down: 4.8 mA
LED Indication :
Ready LED x 1
TX/RX LED x 1
Drives Support : Windows 98, 98SE, ME, 2000, XP
